The Seal Piston 72219 is specifically designed for compatibility with top drive systems in the oil and gas drilling industry, particularly for National Oilwell Varco (NOV) models TDS-11 and TDS-9SA. This critical component is an integral part of the CLAMP CYLINDER ASSEMBLY PH75 (30157287), where it plays an essential role in maintaining hydraulic pressure integrity and preventing fluid leakage under extreme operational conditions. The 72219 seal piston ensures that the clamping mechanism functions properly. Equipment compatibility is crucial when selecting replacement parts, and the 72219 seal piston is engineered to meet exact specifications for these particular top drive models, ensuring optimal performance and reliability in demanding oilfield environments.
The Seal Piston 72219 serves as a critical sealing component within the hydraulic clamping systems of TDS-11 and TDS-9SA top drives. These sophisticated pieces of equipment are essential for modern drilling operations, providing the rotational force necessary to drive the drill string into the earth. Within the CLAMP CYLINDER ASSY PH75 30157287, the Seal Piston 72219 creates an impermeable barrier that maintains pressure within the hydraulic system, preventing fluid bypass and ensuring consistent clamping force. The component must withstand extreme conditions including high pressures, temperature fluctuations, and exposure to various drilling fluids while maintaining dimensional stability. Engineered to meet ISO standards, the Seal Piston 72219 guarantees the highest levels of safety and performance in these demanding applications. When this component fails, it can lead to pressure losses, inefficient operation, and potentially costly downtime. That's why many drilling operations managers choose GMS's high-quality replacement Seal Piston 72219, which delivers the same performance as original parts but at a more competitive price point, making it an ideal solution for budget-conscious maintenance programs without compromising on reliability.
ITEM | DESCRIPTION | OEM Reference Nos | GMS Part Nos |
1 | BODY,CLAMP CYLINDER | 30157221 | 11S00757 |
2 | GATE | 124902 | 11S00758 |
3 | PISTON | 12820 | 11S00759 |
4 | CYLINDER HEAD | 11075 | 11S00760 |
5 | PIN,HINGE | 125013(30175778) | 11S00761 |
6 | RING,CYLINDER HEAD | 11085 | 11S00762 |
7 | SEAL,PISTON | 72219 | 11S00763 |
8 | SEAL,ROD | 72220 | 11S00764 |
9 | RING,WIPER | 72221 | 11S00765 |
10 | WASHER,LOCK,REG | 50905-C | 11S00160 |
11 | SCREW,HEX HD | 50005-20-C5D | 11S00411 |
12 | WASHER,LOCK,REG | 50908-C | 11S00162 |
13 | MANIFOLD ASSEMBLY,CLAMP CYLINDER | 118511 | 11S00769 |
14 | LOCKWIRE,.051 DIA | Z6001 | 11S00167 |
15 | FITTING,GREASE | 53201 | 11S00344 |
16 | STABILIZER,FRONT | 30124898 | 11S00772 |
17 | SCREW,HEX HD,DRILLED SHANK | 117989 | 11S00773 |
18 | NUT,HEX,SLOTTED | 50516-C | 11S00774 |
19 | WASHER | 50816-N-C | 11S00775 |
20 | PIN,COTTER | 51403-14-S | 11S00776 |
21 | RETAINER,HINGE PIN | 120739(30176011) | 11S00777 |
22 | SCREW,HEX HD | 50008-10-C5D | 11S00181 |
23 | LINER,STABILIZER | 30158690 | 11S00779 |
24 | PIN,COTTER | 51402-8-S | 11S00780 |
25 | SPRING,DIE | 79179 | 11S00781 |
26 | MODIFIED,SHOULDER,BOLT | 51710-5-C | 11S00782 |
27 | JAW ASSY,NC 50-5 1/2 FH(φ6.25-7.50) | 30125052 | 11S00783 |
28 | STAB,GUIDE ASSY,NC 50-5 1/2 FH(SET) | 125158 | 11S00784 |
29 | KEY | 16532 | 11S00785 |
30 | SCREW,CAP,SOC HEAD | 50108-14-C | 11S00786 |
31 | WASHER,LOCK,HI COLLAR | 51108-C | 11S00787 |
32 | WASHER,LOCK,REG | 50912-C | 11S00164 |
33 | SCREW,HEX HD | 50012-16-C5D | 11S00144 |
34 | NUT,HEX-SLOTTED | 50508-C | 11S00790 |
Investing in quality replacement Seal Piston 72219 components offers numerous advantages for equipment maintenance teams working with TDS-11 and TDS-9SA top drive systems. The replacement Seal Piston 72219 from GMS is designed to deliver stable performance even in the most challenging drilling environments, maintaining consistent sealing capability throughout extended operational periods. These replacement parts are manufactured under strict quality control processes backed by ISO 9001 certification, ensuring dimensional accuracy and material integrity that matches OEM specifications. The significant cost advantage of these replacement components allows maintenance teams to reduce expenditures without sacrificing performance, making them particularly valuable for non-critical maintenance cycles or when operating under tight budget constraints. Regular replacement of the Seal Piston 72219 during scheduled maintenance intervals helps prevent unexpected failures during crucial drilling operations, minimizing costly downtime and production losses. GMS's replacement parts maintain compatibility with related components 72220 and 72221, enabling comprehensive system maintenance when needed. With consistently available stock and short lead times, maintenance teams can reduce inventory costs while ensuring they have access to essential parts when they need them. This combination of quality, reliability, and cost-effectiveness makes GMS's replacement Seal Piston 72219 an intelligent choice for equipment managers seeking to optimize their maintenance programs.
When installing the Seal Piston 72219 in compatible TDS-11 and TDS-9SA top drive systems, several important factors must be considered to ensure optimal performance and longevity. The installation process requires careful attention to detail, as improper handling or installation can compromise the sealing capabilities of the component. Before installation, technicians should thoroughly clean the cylinder assembly housing to remove any debris, old sealant, or damaged material that could interfere with the new Seal Piston 72219's sealing surface. Proper lubrication is essential during installation to prevent damage to the seal and ensure smooth operation once the system is reassembled and pressurized. The Seal Piston 72219 must be installed with the correct orientation within the CLAMP CYLINDER ASSY PH75 30157287, as specified in the equipment maintenance manual. Technicians should verify that the replacement Seal Piston 72219 matches the original specifications in terms of dimensions, material composition, and performance ratings to maintain equipment integrity. After installation, it's recommended to perform a pressure test at reduced operating pressure before returning the equipment to full service, ensuring that the new Seal Piston 72219 is functioning as expected. This methodical approach to installation helps maximize the service life of the replacement component and maintain the overall reliability of the top drive system, protecting your investment in critical drilling equipment.
The Seal Piston 72219 is an essential component specifically designed for TDS-11 and TDS-9SA top drive systems, playing a crucial role in maintaining hydraulic integrity within the clamping mechanism. GMS offers high-quality replacement options that deliver reliable performance at competitive prices, helping drilling operations optimize maintenance budgets without compromising on equipment reliability. Our ISO 9001 certified manufacturing processes, decade-long industry experience, and commitment to customer satisfaction ensure you receive the right parts when you need them.
Ready to optimize your maintenance program with reliable, cost-effective Seal Piston 72219 replacements? Contact our team today for expert advice on compatible parts for your top drive systems. Email us at sales@gmssupply.com to discuss your specific requirements and discover how GMS can support your drilling operations with quality components and exceptional service.
