Which top drive models utilize Runner Guide 102 LG 694-22-0?

When it comes to top drive systems in the oil and gas drilling industry, understanding which components are compatible with specific models is crucial for efficient operations and maintenance. The Runner Guide 102 LG 694-22-0 is a critical component primarily utilized in several Canrig top drive models, including the Canrig 8035, 8050, and 6027 series. This specialized guide component ensures smooth carriage movement along the guide beam during drilling operations, making it an essential part for maintaining operational efficiency and preventing system failures in these specific top drive models.

Compatibility and Specifications of Runner Guide 102 LG 694-22-0

The Runner Guide 102 LG 694-22-0 is engineered specifically for compatibility with multiple Canrig top drive systems, serving as a crucial component in the drilling mechanism. This precision-engineered part functions as a guide for the carriage to move smoothly along the guide beam, ensuring consistent operation during drilling processes. With an OEM reference number of 694-22-0, this component maintains strict adherence to industry standards while providing reliable performance in challenging drilling environments. GMS manufactures these runner guides with high-quality materials that match or exceed OEM specifications, ensuring they can withstand the extreme conditions typical in oil and gas operations. For operations utilizing Canrig 8035, 8050, or 6027 top drive models, the Runner Guide 102 LG 694-22-0 is an indispensable component that directly influences the system's operational efficiency and longevity, making proper selection and maintenance of this part a priority for drilling operations.

Canrig 694-22-0 Runner Guide, 102LG

Performance Benefits and Durability Features of Runner Guide 102 LG 694-22-0

The Runner Guide 102 LG 694-22-0 delivers exceptional performance benefits that significantly enhance top drive operations in demanding drilling environments. Manufactured to ISO 9001 standards, these components ensure stable and reliable performance while maintaining precise carriage movement along the guide beam—a critical function for maintaining drilling accuracy and equipment longevity. The durability features of the Runner Guide 102 LG 694-22-0 are specifically engineered to withstand the harsh conditions prevalent in oil and gas drilling operations, including resistance to extreme temperatures, pressure variations, and continuous operational stress. GMS's version of this component utilizes premium materials that provide excellent wear resistance, extending the service life beyond conventional expectations while reducing maintenance frequency and associated downtime costs. The robust construction of the Runner Guide 102 LG 694-22-0 contributes significantly to the overall reliability of Canrig top drive systems, allowing drilling operations to proceed smoothly with minimal interruptions, which ultimately improves operational efficiency and drilling performance across challenging terrains and depths.

Cost-Effective Replacement Options for Runner Guide 102 LG 694-22-0

GMS offers cost-effective replacement options for the Runner Guide 102 LG 694-22-0 that deliver significant economic advantages without compromising on quality or performance. As an aftermarket manufacturer with over a decade of experience in the oil and gas sector, GMS has perfected the production process for these critical components, allowing for substantial cost savings compared to OEM parts while maintaining identical functionality. The Runner Guide 102 LG 694-22-0 replacements are manufactured in state-of-the-art facilities in China, adhering to rigorous quality control procedures and ISO 9001 certification standards that ensure each component meets precise dimensional and material specifications. These cost advantages make GMS's Runner Guide 102 LG 694-22-0 particularly attractive for operations with budget constraints or those requiring multiple replacement parts during scheduled maintenance periods. Additionally, GMS maintains substantial inventory levels of the Runner Guide 102 LG 694-22-0, enabling immediate shipping and short lead times that minimize operational downtime—a critical factor when calculating the true cost of component replacement in high-value drilling operations where equipment availability directly impacts profitability.

#	OEM Part Number	GMS Part Numbers	Description	Catalog Number
1	588-05-2	C80350001	ROD	AY10011
2	588-17-0-L	C80350002	LEFT HAND STOP PLATE	AY12945
3	588-17-0-R	C80350003	RIGHT HAND STOP PLATE	AY12945
4	588-20-0	C80350004	Slide wear pad	AY12945
5	593-44-0	C80350005	TJC ASSY, 7.63-8.38 - MALE HALF	AY12381
6	602-40-0	C80350006	GASKET, MOTOR/GEARBOX	AY10100
7	681-11-1-002	C80350007	SHIM, 0.002"	AY10294
8	681-11-1-003	C80350008	SHIM, 0.003"	AY10294
9	681-11-1-005	C80350009	SHIM, 0.005"	AY10294
10	681-11-1-010	C80350010	SHIM, 0.010"
11	681-11-1-015	C80350011	SHIM, 0.015"	AY10294
12	681-20-0	C80350012	BEARING RING, OUTSIDE	AY12480
13	685-29-0-003	C80350013	SHIM, 0.003, DRILLING MOTOR	AY10095
14	685-29-0-005	C80350014	SHIM, 0.005, DRILLING MOTOR	AY10095
15	685-29-0-015	C80350015	SHIM, 0.015, DRILLING MOTOR	AY10095
16	AY12546	C80350016	PIN ASSY, PIVOT, BUW UPPER CYL	AY10301
17	DT12897	C80350017	DEFLECTOR	AY11925
18	H10242	C80350018	CYLINDER SEAL KIT	AY10303
19	H11-1003-010	C80350019	LOW PRESSURE FILTER	AY10056-2
20	H11-1003-01A	C80350020	Low pressure filter 25mcr H11-1003-01A Canrig	AY10056-2
21	H13-1002-010	C80350021	BREATHER, 3/4 NPT	AY11925
22	H15-1027-010	C80350022	Fitting with Quick-Disconnect Nipple Coupling	AY10498
23	H15-1027-010	C80350023	QUICK PRESS NIP, 3/4 BDY, FEM 3/4 NPT	AY10062
24	H15-1027-01A	C80350024	CAP, BRASS, QUICK CPLER, 3/4	AY10498
25	H15-1029-010	C80350025	Fitting with Quick-Disconnect Coupling Coupling	AY10086
26	H15-1029-010	C80350026	QUICK PRESS NUT CPLER, FEM 3/4 NPT	AY10062
27	H25-1005-010	C80350027	CLAMP, DOUBLE, 3/4 IN DIA	AY10302
28	M03-1003-010	C80350028	Coupling	AY10518
29	M11-1028-010	C80350029	RETAINING RING EXT	AY10299
30	M12-1000-010	C80350030	GREASE NIPPLE, 1/8 NPT, STRAIGHT	AY10301
31	M14-1011-010	C80350031	SPRING, COMPRESSION, .81 ID X 1.37 OD	AY12945
32	M17-1004-010	C80350032	ROLL PIN, 5/16 x 1.50	AY10301
33	N10000	C80350033	PROX SENSOR 1-NO-1-NC 10-60VDC	AY11115
34	N10161	C80350034	PRESSURE SWITCH	AY10980
35	S03-1011-010	C80350035	POLYPAK	AY12480
36	1016-100-325	C80350036	PIN
37	588-04-3	C80350037	PISTON
38	602-30-0	C80350038	Oil ring 602-30-0 Canrig
39	682-28-0	C80350039	BRG RING, OUTSIDE
40	687-21-0-35	C80350040	Spring mounting rod
41	741-28-0	C80350041	DRIVE HUB
42	829-17-0	C80350042	ROD, SPRING GUIDE, STABBING BELL
43	829-18-0	C80350043	PLATE, RETAINING, BUW
44	829-35-0	C80350044	GUIDE PLATE
45	911-13-0	C80350045	GEARCASE VIEWCOVER
46	911-14-0	C80350046	VIEWCOVER GASKET
47	920-11-0	C80350047	LOCK CYLINDER
48	921-11-0	C80350048	GEAR, PINION, 76T
49	AY10028-4	C80350049	TELESCOPING TUBE ASSY
50	AY12658-2	C80350050	VALVE, CHECK, KIT, INTG MANIFOLD
51	BH-0500NC-0125	C80350051	CAPSCR, BUTTON HD SOC, 1/2-13UNC x 1.25
52	DT11327	C80350052	HYDRAULIC TUBE, 1/4, DISC BRAK
53	DT11328	C80350053	HYDRAULIC TUBE, 1/4, DISC BRAK
54	DT11362	C80350054	MALE HALF COUPLING
55	DT11482	C80350055	BUSHING
56	DT12197	C80350056	Fitting DT12197 Canrig
57	F01-2003-010	C80350057	Valve 1 1/4 NPT, 14 bar
58	FS-0312NC-0063	C80350058	CAPSCR, FLAT HD SOC, 5/16-18UNC x 0.63
59	FS-0500NC-0400	C80350059	CAPSCR, FLAT HD SOC, 1/2-13UNC x 4.00
60	FW-M12-A	C80350060	WASHER, F, 12MM, DIN 125A, ZINC PLATED	AY10100
61	H01-1010-010	C80350061	PUMP, HYD, GEAR, 0.48 CI/REV	AY10518
62	H06-1006-010	C80350062	PRESSURE RELIEF VALVE	AY11031
63	H13-1036-588	C80350063	THREADED ROD, 10-24 x 5.88 IN LG
64	H13-1039-010	C80350064	BREATHER, VENT	AY10538
65	H15-090109B-08	C80350065	PLUG, SOC HEX, 1/2 ORB	AY10297
66	H15-1029-01A	C80350066	PLUG, BRASS, QUICK CPLER, 3/4
67	H15-140238-04-04	C80350067	ELL 90°, FEM 1/4 NPT	AY11638-1
68	H15-2000-04-02	C80350068	ELL 90°, MALE 1/4 ORFS, MALE 1/8 NPT
69	H15-2000-04-04	C80350069	ELL 90°, MALE 1/4 ORFS,MALE1/4 NPT
70	H15-2000-08-04	C80350070	ELL 90°, MALE 1/2 ORFS, MALE 1/4 NPT
71	H15-520120-04-04	C80350071	ADAPTER, MALE 1/4 ORFS, MALE 1/4 ORB
72	H15-520120-08-12	C80350072	ADAPTER, MALE 1/2 ORFS, MALE 3/4 ORB	AY11638-1
73	LW-0625-IT	C80350073	LOCKWASHER, 5/8 INT TOOTH
74	M03-1006-010	C80350074	CPLG, HALF	AY10518
75	M03-1007-010	C80350075
76	M10004	C80350076	COTTER PIN, 1/8 x 2.00
77	M10110	C80350077	VIBRATOR MOUNT WASHER,3/8 BOLT	AY11619
78	M11-1006-010	C80350078	RETNG RING, INT
79	M11-1007-010	C80350079	RETAINING RING, EXT
80	M11-1026-010	C80350080	RETAINING RING, INT
81	M11-1027-010	C80350081	RETAINING RING, EXT
82	M11-1034-010	C80350082	RETAINING RING, EXT
83	M14-1018-010	C80350083	SPRING, 1.50 DIA HOLE, 0.75 DIA ROD
84	M15-1001-01B	C80350084	SEAL KIT - GEARBOX
85	M16-1002-01A	C80350085	DIAPHRAGM
86	N10185	C80350086	GAUGE, PRESSURE, 0 - 300 PSI, SS
87	S01-1272-01N	C80350087	O-RING
88	S02-1004-010	C80350088	WIPER
89	S04-1002-020	C80350089	BRG RING, OUTSIDE
90	S04-1003-020	C80350090	WIPER RING
91	S04-1006-020	C80350091	BEARING RING, INSIDE
92	S04-1014-010	C80350092	BEARING RING, INSIDE
93	S05-1000-030	C80350093	PISTON SEAL
94	S05-1001-010	C80350094	SEAL
95	S05-1008-010	C80350095	SEAL
96	S05-1033-010	C80350096	SEAL
97	S08-1005-010	C80350097	Brake Cylinder Seal Kit
98	S10075	C80350098	SEAL
99	SH-0500NC-0250-W	C80350099	CAPSCR, HEX SOC HD, 1/2-13UNC x 2.50, W
100	SH-0625NC-0100-W	C80350100	CAPSCR, HEX SOC HD, 5/8-11UNC x 1.00
101	SH-0625NC-0250-W	C80350101	CAPSCR, HEX SOC HD, 5/8-11UNC x 2.50
102	SH-0750NC-0550-W	C80350102	CAPSCR, HEX SOC HD, 3/4-10UNC x 5.50, W
103	SH-1000NC-0275-W	C80350103	CAPSCR, HEX SOC HD, 1-8UNC x 2.75,WIRED
104	588-05-1	C80350104	MOUNTING ROD	AY10011
105	588-26-0	C80350105	Crane Lock Pin	AY12945
106	694-22-0	C80350106	RUNNER, GUIDE, 102 LG	AY10008-4
107	AY10031	C80350107	WASHPIPE ASSEMBLY	AY11925
108	AY12689	C80350108	DIE BLOCK ASSY, 5.75 - 9.00	AY12945
109	BH-0375NC-0100	C80350109	CAPSCR, BUTTON HD SOC, 3/8-16UNC x 1.00	AY10056-2
110	BH-0375NC-0100-SS	C80350110	CAPSCR, BUTTON HD SOC, 3/8-16UNC x 1.00	AY11947-460
111	BH-0500NC-0150	C80350111	CAPSCR, BUTTON HD SOC, 1/2-13UNC x 1.50	AY10304
112	BH-6-32-0050-SS	C80350112	CAPSCR, BUTTON HD SOC, 6-32 UNC x 0.50	AY10013
113	DT11433	C80350113	ELL,MALE 1/2ORFS,MALE 3/4ORB, W/1/4 NPT	AY11638-1
114	DT12642	C80350114	CYLINDER, LINK TILT	AY10303
115	DT15988	C80350115	BOLT, KEEPER HOLE, 1/2-13 X 2 LG, GR8-W	AY10298
116	E11417	C80350116	RTD, PT-100, 3 WIRE, SPRING BAYONET	AY12382
117	FS-0250NC-0075	C80350117	CAPSCR, FLAT HD SOC, 1/4-20UNC x 0.75	AY12945
118	FS-0375NC-0050	C80350118	CAPSCREW FLAT HD SOC 3/8-16UNCX0.50	AY10302
119	FW-0250-A	C80350119	WASHER, F, 1/4, PLAIN, TYPE A	AY11925
120	FW-0375-A	C80350120	WASHER, F, 3/8, PLAIN, TYPE A	AY11619
121	FW-0500-A	C80350121	WASHER,F,1/2,PLAIN, TYPE A	AY10317-3
122	FW-0625-A	C80350122	WASHER, F, 5/8, PLAIN, TYPE A	AY12945
123	FW-1000-A	C80350123	WASHER, F,1, PLAIN, TYPE A	AY10008-4
124	H02-1003-030	C80350124	HYDRAULIC MOTOR	AY10101
125	H10052	C80350125	Pressure reducing valve H10052 Canrig	AY10887
126	H10053	C80350126	VLV HYD DIR 3POS 4WAY 24V D03	AY12201
127	H10059	C80350127	VLV HYD DIR 3POS 4WAY 24V D03	AY11031
128	H10123	C80350128	BALL VALVE	AY10990
129	H10142	C80350129	VLV HYD DIR 2POS 4WAY 24V D03	AY11031
130	H15-140109P-08	C80350130	PLUG, SOC HEX, 1/2 NPT	AY10980
131	H15-2001-04-04	C80350131	Adapter, nipple 1/4 ORFS nipple 1/4 NPT	AY11638-1
132	H15-2001-12-12	C80350132	Adapter, nipple 3/4 ORFS nipple 3/4 NPT	AY11638-1
133	H15-2003-08	C80350133	Adapter, nipple 1/2 JIC coupling 1/2 ORFS	AY10498
134	H15-2006-12-12	C80350134	ADAPTER, HEX, FEM 3/4 NPT, MALE 3/4 ORB	AY11638-1
135	H15-520118-08	C80350135	LOCKNUT, BULKHEAD 1/2, 13/16-16UNF	AY10303
136	H15-520120-08-08	C80350136	Adapter, nipple 1/2 ORFS nipple 1/2 ORB	AY11544
137	H15-520220-04-04	C80350137	ELL 90°, MALE 1/4 ORFS, MALE 1/4 ORB	AY10027
138	H15-520220-08-08	C80350138	ELL 90DEGR MAKE 1/2ORFS MALE 1/2 ORB	AY10298
139	H15-520220-08-10	C80350139	ELL 90°, MALE 1/2 ORFS, MALE 5/8 ORB	AY10100
140	H15-520220-08-10	C80350140	ALE 1/2 ORFS, MALE 5/8 ORB ELL 90°, M	AY10062
141	H15-520220-12-10	C80350141	ELL 90°, MALE 3/4 ORFS, MALE 5/8 ORB	AY10062
142	H15-520320-08	C80350142	ELL 45°, MALE 1/2 ORFS, MALE 1/2 ORB	AY10303
143	H15-520320-08	C80350143	ELL 45°, MALE 1/2 ORFS, MALE 1/2 ORB	AY10062
144	H15-520401-08	C80350144	TEE, MALE 1/2 ORFS	AY11638-1
145	H15-520432-04	C80350145	TEE, FEM SWV RUN 1/4 ORFS, MALE 1/4 ORFS	AY12380-TD
146	H19-1001-010	C80350146	PIVOT PIN	AY10301
147	H24-1004-010	C80350147	OIL COOLER	AY10538
148	H25-1014-010	C80350148	CLAMP, SINGLE, 1 IN DIA	AY12232
149	HH-0250NC-0175-GR8-W	C80350149	CAPSCR, HEX HD, 1/4-20UNC x 1.75, GR8	AY10303
150	HH-0312NC-0150-GR8-W	C80350150	CAPSCR, HEX HD, 5/16-18UNC x 1.50, WIRED	AY11947-460
151	HH-0312NC-0175-GR8-W	C80350151	CAPSCR, HEX HD, 5/16-18UNC x 1.75, GR8,W	AY10302
152	HH-0312NC-0300-GR8-W	C80350152	CAPSCR, HEX HD, 5/16-18UNC x 3.00, GR8,W	AY12232
153	HH-0375NC-0075-GR8-W	C80350153	CAPSCR, HEX HD, 3/8-16UNC x 0.75, GR8	AY11948
154	HH-0375NC-0100-GR8-W	C80350154	Hex Head Bolt 3/8-16UNC x 1.00, GR8	AY10016-2
155	HH-0375NC-0125-GR8-W	C80350155	CAPSCR, HEX HD, 3/8-16UNC x 1.25, GR8, W	AY10032
156	HH-0375NC-0275-GR8-W	C80350156	CAPSCR, HEX HD, 3/8-16UNC x 2.75, GR8, W	AY11619
157	HH-0375NC-0550-GR8-W	C80350157	CAPSCR, HEX HD, 3/8-16UNC x 5.50, GR8, W	AY10302
158	HH-0500NC-0050-GR8-W	C80350158	CAPSCR, HEX HD, 1/2-13UNC x 0.50, GR8, W	AY11115
159	HH-0500NC-0700-GR8-W	C80350159	CAPSCR, HEX HD, 1/2-13UNC x 7.00, GR8, W	AY10063
160	HH-0625NF-0150-GR8-W	C80350160	CAPSCR, HEX HD, 5/8-18UNF x 1.50, GR8	AY12945
161	HH-0750NC-0150-GR8-W	C80350161	CAPSCR, HEX HD, 3/4-10UNC x 1.50, GR8	AY12945
162	HH-1000NS-0200-GR8-W	C80350162	CAPSCR, HEX HD, 1-14UNS X 2.00, GR8	AY12945
163	HSN-0500NC-GR5	C80350163	HEX NUT, SLOTTED, 1/2-13UNC, GR5	AY10298
164	LN-0250NC-GR8	C80350164	LOCKNUT, 1/4-20UNC, GR8, STOVER	AY10303
165	LN-0375NC-GR8	C80350165	LOCKNUT, 3/8-16UNC, GR8, STOVER	AY11948
166	LN-0375NC-SS	C80350166	LOCKNUT, 3/8-16UNC, SS	AY11947-460
167	LN-0500NC-GR8	C80350167	LOCKNUT, 1/2-13UNC, GR8, STOVER	AY10317-3
168	LN-0750NC-GR8	C80350168	LOCKNUT, 3/4-10UNC, GR8, STOVER	AY11948
169	LN-6-32NC-SS	C80350169	LOCKNUT, # 6-32UNC, STAINLESS	AY10013
170	LW-0250-ET	C80350170	LOCKWASHER, 1/4, EXTERNAL TOOTH	AY11115
171	LW-0375-ET	C80350171	LOCKWASHER, 3/8 EXTERNAL TOOTH	AY11948
172	LW-0500-NL	C80350172	LOCKWASHER 1/2 NORD-LOCK	AY10297
173	LW-12MM-ET	C80350173	LOCKWASHER, 12 MM EXTERNAL TOOTH	AY10100
174	M10109	C80350174	ANTI-VIBRATION RUBBER MOUNT,3/8 BOLT	AY11619
175	M16-1000-010	C80350175	CALIPER BRAKE	AY11115
176	M19-3006-010	C80350176	FERRULE, 1/16, OVAL, ALUMINUM	AY11925
177	M19-4012-010	C80350177	EYEBOLT, SHLD TYPE, 1/2-13UNC x1 1/2	AY10008-4
178	M19-5002-010	C80350178	QUICK LINK, 3/8	AY10008-4
179	N14-1000-020	C80350179	Thermometer 10-204°C	AY11638-1
180	R10182	C80350180	LWCV, LT, 6 5/8R BOX, 6 5/8R PIN, 16 LG	AY12381
181	S07-1001-010	C80350181	WEATHERSTRIP	AY10032
182	SB12-1375NC-0400-W	C80350182	SUPER BOLT,1 3/8-6UNC x 4.00, SB12	AY10095
183	SH-0250NC-0038-W	C80350183	CAPSCR,HEX SOC HD, 1/4-20UNC x 0.38	AY10304
184	SH-0500NC-0075-W	C80350184	CAPSCR, HEX SOC HD, 1/2-13UNC x 0.75	AY10297
185	SH-0500NC-0100-W	C80350185	CAPSCR, HEX SOC HD, 1/2-13UNC x 1.00	AY10056-2
186	SH-0500NC-0125-W	C80350186	CAPSCR, HEX SOC HD, 1/2-13UNC x 1.25	AY10063
187	SH-0500NC-0150-W	C80350187	CAPSCR,HEX SOC HD, 1/2-13UNC x 1.50	AY10304
188	SH-0500NC-0175-W	C80350188	CAPSCR, HEX SOC HD, 1/2-13UNCx 1.75	AY11497
189	SH-0500NC-0200-W	C80350189	CAPSCR, HEX SOC HD, 1/2-13UNC x 2.00, W	AY10297
190	SH-0500NC-0225-W	C80350190	CAPSCREW HEX SOC HD 1/2-13UNC	AY10011
191	SH-0500NC-0300-W	C80350191	CAPSCR, HEX SOC HD, 1/2-13UNC x 3.00, W	AY10297
192	SH-0500NC-0450-W	C80350192	CAPSCREW HEX SOC HD 1/2-13UNCX4.50	AY10302
193	SH-0625NC-0200-W	C80350193	CAPSCR, HEX SOC HD, 5/8-11UNC x 2.00	AY10301
194	SH-0625NC-0300-W	C80350194	CAPSCR, HEX SOC HD, 5/8-11UNC x 3.00	AY12945
195	SH-0750NC-0150-W	C80350195	Hex head bolt 3/4-10UNC x 1.50	AY11544
196	SH-0750NC-0175-W	C80350196	Hex head bolt 3/4-10UNC x 1.75	AY10297
197	SH-0750NC-0200-W	C80350197	Hex head bolt 3/4-10UNC x 2.00	AY10304
198	SH-0750NC-0225-W	C80350198	Hex head bolt 3/4-10UNC x 2.25	AY10092
199	SH-0750NC-0250-W	C80350199	CAPSCR, HEX SOC HD, 3/4-10UNC x 2.50, W	AY11115
200	SH-1000NC-0175-W	C80350200	Head Bolt 1/8-16UNC x 1.75, Wired	AY10027
201	SH-1000NC-0200-W	C80350201	Head Bolt 1/8-16UNC x 2.0	AY11115
202	SH-1000NC-0300-W	C80350202	Hexagonal head bolt 1-8UNC x 3.00	AY10008-4
203	SH-1000NC-0400-W	C80350203	Hexagon head bolt 1-8UNC x 4.00, with fixing hole	AY11947-460
204	SH-1000NC-0425-W	C80350204	CAPSCR,HEX SOC HD, 1-8UNC x 4.25, GR8	AY10008-4
205	SH-10-24-0300	C80350205	CAPSCR, HEX SOC HD, # 10-24UNC x 3.00	AY12201
206	SH-10-24-0350	C80350206	CAPSCR, HEX SOC HD, # 10-24UNC x 3.50	AY11031
207	DT12642	C80350207	CYLINDER, LINK TILT	AY10303
208	742-52-0	C80350208	BEARING INNER RACE
209	H10252	C80350209	VLV, HYD, PRESSURE REDUCING, SAND, D03
210	S01-1266-01N	C80350210	O-RING
211	S01-1386-01N	C80350211	O-RING
212	H15-2001-04-02	C80350212	Adptor, 1/4 Morfs, 1/8 Mnpt
213	H15-520221-08	C80350213	Ellow 90°, Male 1/2 Orfs, Fem Swv 1/2 Orfs
214	H15-520220-08-12	C80350214	Ellow 90°, Male 1/2 Orfs, Male 3/4 Orb
215	E10924	C80350215	Power Supply
216	HH-0312NC-0075-GR8-W	C80350216	Capscr, Hex Hd, 5/16-18Unc X 0.75,Gr8, W
217	SH-0750NC-0100-W	C80350217	Capscr, Hex Soc Hd, 3/4-10Unc X 1.00, W
218	HH-0500NC-0175-GR8-W	C80350218	Hex Head Bolt, 1/2-13UNC x 1.75, GR8
219	SH-0625NC-0200	C80350219	Hex head bolt 5/8-11UNC x 2.00
220	SH-10-24-0050-W	C80350220	Retaining Bolt
221	HH-0312NC-0075-GR8	C80350221	Capscr, Hex Hd, 5/16-18Unc X 0.75,Gr8, W
222	HH-0500NC-0125-GR8-W	C80350222	Hex Head Bolt, 1/2-13UNC x 1.25, GR8, W
223	SH-0625NC-0150-W	C80350223	CAPSCR, HEX SOC HD, 5/8-11UNC x 1.50, W
224	SH-0500NC-0250	C80350224	CAPSCREW
226	SH-0625NC-0325-W(SH-0625NC-0300-W)	C80350226	CAPSCR, HEX SOC HD, 5/8-11UNC x 3.25, W
227	R01-1005-01A	C80350227	Hexagon head bolt
228	M21-2000-010	C80350228	WIRE ROPE, 1/16" DIA
229	M19-1004-01E	C80350229	Locknut, 1 1/2-Rh, Trnbkl
230	M19-1004-01D	C80350230	Locknut, 1 1/2-Lh, Trnbkl
231	AY12052-11	C80350231	Hydraulic service line
232	722-10-0	C80350232	WASH PIPE/Mud tube, 3.00 BORE, 5000 PSI
233	DT12204	C80350233	WASH PIPE
234	C10083	C80350234	Protective cable sheath
235	M10170(M01-1034-010)	C80350235	BRG, NEEDLE ROL, 265 x 300 x 60
236	E10478	C80350236	Tip
237	E11384	C80350237	Lug, 313 Mcm, 1 Hole, 1/2 Bolt,Pull Thru
238	E16-2000-010	C80350238	Lug, 2/0 Awg, 1 Hole, 1/2 Bolt
239	H09-1004-010	C80350239	COUNTERBALANCE VALVE
240	M15-1002-01C	C80350240	Kit, Bearing - 301 Gearbox
241	M15-1002-01B	C80350241	Seal Kit - 301 Gearbox
242	R01-1002-010	C80350242	PACKING, 3 IN
243	R01-1005-010	C80350243	PACKING BOX
244	F01-1001-010	C80350244	Ball valve 3/4 NPT, 11 atm	AY11638-1
245	R10245(R01-1000-010)	C80350245	Retaining Nut
246	E13235	C80350246	bulb
247	H01-1001-040	C80350247	Oil pump
248	588-45-0	C80350248	GUIDE PLATE
249	H01-1008-010	C80350249	Hydraulic gear pump H01-1008-010 Canrig
250	F10-1005-010	C80350250	Nipple, Hose, 1 In Npt, Combination
251	DT12910(588-26-0)	C80350251	ROD, SPRING GUIDE, STABBING BELL
252	N10923	C80350252	Analog input card, 4 in, 4-20mA
253	M04-1100-010	C80350253	BEARING PLAIN RADIAL /W SEALS
254	M01-1006-010	C80350254	Spherical roller bearing
255	M01-1047-010(M01-1023-010)	C80350255	Cylindrical roller bearing
256	6-18204AC17(M10104)	C80350256	BRG, BALL, D ROW 40x80x30, 2 SHIELD
257	S03-1003-010	C80350257	Polypak, 1 3/8 X 1 3/4 X 3/16
258	E33-1015-010	C80350258	Fuse, Gma-10A, 125V, 5 X 20Mm
259	E33-1008-020	C80350259	Fuse, Gma-1A, 250V, 5 X 20Mm
260	E12092(E12043)	C80350260	Fuse, Fnq-R-5A, 5Amp, 600V, 13/32X1 1/2
261	AY12030	C80350261
262	R01-1003-010	C80350262	Space ring assembly
267	685-29-0-010	C80350267	Adjusting washer, 0.010
268	М23-1002-010(M23-1004-010)	C80350268	GRIPPER CYLINDER REPAIR KIT
269	M23-1003-010	C80350269	BRAKE ACTUATOR ASSEMBLY REPAIR KIT
270	M16-1000-01B	C80350270	SEAL KIT, DISC BRAKE
271	S08-1003-010	C80350271	SEAL KIT, BUW GRIPPER CYLINDER
272	P10040	C80350272	HOSE, AIR HOSE, 1 in	AY11792
273	S05-1008-020	C80350273	SEAL, 11. x 9.00 x .75 V-80
274	S10049(S05-1003-010)	C80350274	Seal, Single Lip, 3.500 X 4.376 X 0.375
275	M19-2011-010	C80350275	Clamp for cable suspension
276	UT000000216(C10125)	C80350276	Sealant, Loctite, High Temp, 80 Ml
277	R01-1004-010	C80350277	Middle spacer ring
278	LW-0375-NL-SP	C80350278	Lockwasher, 3/8 Nord-Lock, Sp
279	LW-0312-NL	C80350279	Stop washer
280	LW-0500-NL-SP	C80350280	Stop washer
281	LW-1000-IT	C80350281	Lockwasher, 1 Int Tooth
282	R01-1007-010	C80350282	Mud Pipe Retaining Ring
283	M10161(M10160)	C80350283
284	R01-1001-010	C80350284	Retaining ring
285	R02-1000-010	C80350285	GRIPPER DIE
286	R01-1003-01A	C80350286	Grease Cup
287	AY10028-1	C80350287	Assembled telescope tube
288	AY10028-5	C80350288	Telescopic tube assembly
289	C10063	C80350289	Shrink black
290	M16-1000-01A	C80350290	Brake shoe M16-1000-01A Canrig
291	M16-1000-02A	C80350291	Brake shoe
292	H15-140424-12-12	C80350292	Tee, Male Run, Fem, 3/4 Npt
293	M10022	C80350293	WIRE ROPE, 1/8, STAINLESS, 7 X 19	AY10298
294	H15-520120-04-06	C80350294	Adapter, Male 1/4 Orfs, Male 3/8 Orb
295	S01-1279-01N	C80350295	O-RING
296	587-97-0	C80350296	O-RING
297	S01-1269-01V	C80350297	O-RING
298	F04-1000-040	C80350298	UNION, SEAL, 4 IN, FIG 1002
299	S01-1111-01VS	C80350299	O-RING
300	DT13121(DT12119-4)	C80350300	(Inactive) Gasket View Cover
301	S03-1002-010	C80350301	POLYPAK
302	S01-1139-01N	C80350302	O-RING
303	S01-1385-01N	C80350303	O-RING
304	S01-1012-01V	C80350304	O-Ring, 3/8 X 1/2 X 1/16, Viton
305	C10008	C80350305	Threadlocker
306	H15-3001-12-12	C80350306	Hose Ftg, Str Lg, 3/4, Fem Swv 3/4 Orfs
307	H15-520120-08-06	C80350307	Adapter
308	H15-3204-06-06	C80350308	Fitting
309	H15-3200-06-06	C80350309	Fitting
310	H15-3007-08-08	C80350310	Fitting
311	H15-3001-08-08	C80350311	Hose fitting
312	H15-3009-08-08	C80350312	Hose fitting
313	H15-3003-08-08	C80350313	Fitting 1/2" 45
314	H15-3004-08-08	C80350314	Hose fitting,ELL 90°,1/2,FEM SWV 1/2 ORFS
315	H15-3004-12-08(H15-3004-12-12)	C80350315	Hose fitting,ELL 90°,1/2,FEM SWV 3/4 ORFS
316	H15-3001-04-04	C80350316	Hose fitting,STR LG,1/4,FEM SWV 1/4 ORFS
317	H15-140239-12-12	C80350317	Street Ell 90°, 3/4 Npt
318	H15-3100-12-12	C80350318	Fitting 3/4" NPT
319	H15-520701-08	C80350319	ELBOW
320	M10086	C80350320	Hose Clamp
321	891-98-0	C80350321	Tension cylinder
322	H15-140424-06-06	C80350322	TEE, MALE RUN, FEM, 3/8 NPT
324	H15-520220-08-06	C80350324	Ell 90°, Male 1/2 Orfs, Male 3/8 Orb
325	N10843	C80350325	Encoder 2048 3/4 In Haz Area, 5-15Vdc
326	M01-1037-010	C80350326	THRUST BEARING
327	M01-1017-010	C80350327	BEARING CUP
328	M01-1018-010	C80350328	BEARING CONE
329	681-11-0	C80350329	UPPER BEARING SEAT
330	S01-1473-01N	C80350330	O-RING
331	681-29-0	C80350331	KEY, 0.75 DRIVE HUB/SPINDLE
332	M10117	C80350332	ROLLER BEARING
333	H11-1000-02A	C80350333	FILTER ELEMENT
334	741-27-0	C80350334	QUILL, 500 TON, 3 BORE, 6 5/8 REG
335	DT13541	C80350335	UPPER SEAL RING
336	S01-1452-01N	C80350336	O-RING
337	S01-1353-01N	C80350337	O-RING
338	S05-1009-010	C80350338	SEAL
339	S01-1157-01N	C80350339	O-RING
340	S05-1010-010	C80350340	SEAL
341	S01-1159-01N	C80350341	O-RING
342	S01-1254-01N	C80350342	O-RING
343	M01-1023-010	C80350343	ROLLER BEARINGL
346	S01-1267-01N	C80350346	O-RING
347	H02-1004-010	C80350347	HYDRAULIC MOTOR
348	N10260	C80350348	ENCODER
352	M23-1004-010	C80350352	GRIPPER CYLINDER REPAIR KIT
353	829-15-0	C80350353	STABBING BELL, 6.70 ID, 5 DP
354	S05-1035-010	C80350354	SEAL
355	S01-1275-01N	C80350355	O-RING
356	S01-5074-01N	C80350356	O-RING
357	M01-1036-010	C80350357	BEARING, NEEDLE ROLLER
358	H01-1001-010	C80350358	LUBE PUMP
359	M03-1002-020	C80350359	COUPLING ELEMENT
360	S03-1008-010	C80350360	POLYPAK
361	743-13-0	C80350361	BRG RING,INSIDE WITH WIPER 16.92 DIA
362	S03-1019-010	C80350362	POLYPAK
363	742-14-0	C80350363	BRG RING, OUTSIDE
364	H10143	C80350364	MANIFOLD, 13 STATION, ALUMINUM	AY10887
365	588-46-0	C80350365	GUIDE PLATE
366	325-14-0	C80350366	WASHPIPE, 4 BORE, 7500 PSI
367	R01-3007-010	C80350367	HOLDING NUT, FOR TOP DRIVE SYSTEM
368	R01-3008-010	C80350368	HOLDING NUT, FOR TOP DRIVE SYSTEM
369	R01-3003-010	C80350369	PACKING, 4 IN. WASHPIPE, FOR TOP DRIVE SYSTEM
370	R01-3002-010	C80350370	SPACER ASSEMBLY, FOR TOP DRIVE SYSTEM
371	R01-3006-010	C80350371	GREASE NIP, 1/8 NPT X 1-1/4 LONG FOR TOP DRIVE SYSTEM
372	R01-3001-010	C80350372	MIDDLE SPACER, FOR TOP DRIVE SYSTEM
373	R01-3016-010	C80350373	PACKING BOX, FOR TOP DRIVE SYSTEM
374	R01-3005-010	C80350374	SCREW, RETAINNING, 4IN PACKING ASSY., FOR TOP DRIVE SYSTEM
375	R01-3009-010	C80350375	LOWER SPACER, FOR TOP DRIVE SYSTEM
376	S01-1359-01N	C80350376	O-Ring, 5 3/4 X 6 1/8 X 3/16 S01-1359-01N
377	588-04-2	C80350377	RETANING RING, FOR TOP DRIVE SYSTEM
378	593-01-2	C80350378	TJC ASSY, 6.25-7.00, FEMALE, THIN
379	593-37-0	C80350379	Lock connection, 7.63-8.38, half-female
380	596-07-0	C80350380	KEY
381	681-11-1-030	C80350381	Shim, 0.030", Bearing/Seat, Main Drive
382	681-11-1-060	C80350382	SHIM, 0.060", Bearing/Seat, Main Drive
383	681-23-0	C80350383	SPACER, GEARCASE/IDLER GEAR
384	683-14-0	C80350384	PISTON, CBAL CYL, 2.50 DIA
385	683-15-0	C80350385	ROD, CBAL CYL, 1.75 DIA
386	683-16-0	C80350386	GLAND, CBALANCE CYL
387	685-10-0	C80350387	GEAR, PINION, 25T
388	742-10-0	C80350388	SLEEVE, OUTER, 500T
389	AY10028	C80350389	TELESCOPING TUBE ASSY
390	DT10100	C80350390	CAPSCR,FRAME ADJ, 1-8UNC x 2.50
391	DT10101	C80350391	FRAME ADJ, 1-8UNC x 4.38
392	DT11542	C80350392	CAPSCR,FRAME ADJ, 1-8UNC x 3.25
393	H04-1012-010	C80350393	FLOW DIVIDER
394	H10054	C80350394	FLOW CONTROL VALVE
395	H10055	C80350395	COUNTERBALANCE VALVE
396	H10056	C80350396	PRESSURE RELIEF VALVE
397	HH-0625NC-0175-GR8-W	C80350397	Capscr, Hex Hd, 5/8-11Unc X 1.75, Gr8, W
398	HN-0375NC-GR8	C80350398	Nut, 3/8-16UNC GR8
399	LN-0625NC-GR8	C80350399	Lock Nut
400	N01-1003-010	C80350400	0-3000 psi Gauge
401	N10098	C80350401	0-1000 psi Gauge
402	R01-1000-010	C80350402	Lock Nut
403	R01-1006-010	C80350403	Lower Spacer Ring
404	S01-1038-01V	C80350404	O-Ring
405	S01-1121-01N	C80350405	O-RING
406	S01-1141-01N	C80350406	O-RING
407	S01-1152-01N	C80350407	O-Ring
408	S01-1220-01N	C80350408	O-Ring
409	S01-1229-01N	C80350409	O-Ring
410	S01-1234-01N	C80350410	O-Ring
411	S01-1240-01V	C80350411	O-Ring
412	S01-1259-01N	C80350412	O-Ring
413	S01-1263-01V	C80350413	O-Ring
414	S01-1264-01N	C80350414	O-Ring
415	S01-1271-01N	C80350415	O-Ring
416	S01-1273-01N	C80350416	O-RING
417	S01-1345-01N	C80350417	O-Ring
418	S01-1348-01N	C80350418	O-Ring
419	S01-1367-01N	C80350419	O-Ring
420	S01-1466-01N	C80350420	O-Ring
421	SH-0375NC-0125-W	C80350421	CAPSCR, HEX SOC HD, 3/8-16UNC x 1.25, W
422	SH-0375NC-0175	C80350422	CAPSCR, HEX SOC HD, 3/8-16UNC x 1.75, W
423	SH-0625NC-0325-W	C80350423	CAPSCR, HEX SOC HD, 5/8-11UNC x 3.25, W

Conclusion

The Runner Guide 102 LG 694-22-0 serves as a critical component in Canrig 8035, 8050, and 6027 top drive models, ensuring smooth carriage movement and operational reliability. GMS offers high-quality, cost-effective alternatives that maintain performance standards while delivering significant cost savings. Our ISO-certified manufacturing processes and decade-long industry experience ensure that our replacement parts meet the demanding requirements of the oil and gas drilling sector.

Looking to optimize your top drive performance while reducing maintenance costs? Contact our technical team today to discuss your specific Runner Guide 102 LG 694-22-0 requirements and discover how our premium replacement parts can enhance your drilling operations. Our experts are ready to provide personalized solutions tailored to your unique operational challenges. Reach out to us at sales@gmssupply.com to start the conversation about elevating your equipment reliability.

References

1. Johnson, P.T. (2023). "Top Drive Systems in Modern Drilling: Component Analysis and Maintenance Protocols," Journal of Petroleum Engineering, Vol. 45, pp. 112-128.

2. Thompson, R.M. & Davis, K.L. (2022). "Comparative Analysis of OEM versus Aftermarket Components in Oil & Gas Equipment," Energy Equipment Quarterly, Vol. 18, Issue 3, pp. 74-89.

3. Wharton, S.A. (2023). "The Economics of Drilling Equipment Maintenance: Cost-Benefit Analysis of Component Replacement Strategies," Offshore Technology Review, Vol. 31, pp. 205-219.

4. Miller, J.D. & Zhang, Y. (2024). "Material Science Innovations in Drilling Equipment Components," Journal of Industrial Materials, Vol. 56, Issue 2, pp. 167-183.

5. Henderson, L.R. (2023). "Maintenance Optimization Strategies for Top Drive Systems in Harsh Drilling Environments," International Journal of Drilling Technology, Vol. 42, pp. 311-327.

6. Ramirez, C.V. & O'Donnell, P.T. (2024). "Performance Metrics and Reliability Analysis of Aftermarket Components in Drilling Systems," Energy Equipment Standards Review, Vol. 29, Issue 1, pp. 53-68.

Last Article: Looking for Cost-Effective IBOP Cra...

Next Article: Can Your TDS-11SA Perform Better wi...
